For system volumes of 10,000 - 20,000L

DIMENSIONS (LxWxH): 3775 x 1650 x 2810 mm

SYSTEM WATER VOL (L) : 3443

DRY WEIGHT (KG): 513

WET / RUNNING WEIGHT (KG): 3956

POWER SUPPLY: 380V / 50Hz (110V available)

MAX POWER CONSUMPTION (kW): 2.49

RETURN PUMP: Badu Prime 30-AK

CIRCULATION PUMP: DC controllable, 220 W, 30,000 l/hr

SUMP: White PP, 2650L vol.

PROTEIN SKIMMER: Acrylic Body, Controllable Needle Wheel DC pump 20,000 l/hr

BIOLOGICAL FILTRATION: MBBR Chamber, K3 Media

DEGAS / TRICKLE CHAMBER: Bio-balls degas media

PARTICULATE FILTER: High Pressure Sand filter, Fibreglass body, viewing window, 350kg silica sand, 900mm dia.

UV STERILISER: High Output, PVC body, 240 W

PREFILTERS: 8 x 100 micron, 430 x 170 mm dia.

OCEANYX systems offer a wide range of upgrades and customizable options depending on the application and end user preference. Options include:

• Automated operating system

• Digital water parameter monitoring (Lab grade probes): Temperature / Salinity / KH / PH / ORP

• Water level monitoring / Automatic Top-up

• Water mixing / Top-up reservoir

• Automatic dosing system

• Ozone injection / Degassing system

• Water Chiller / Heat exchanger

• Remote monitoring and alarm from mobile Device
