For system volumes of 20,000-30,000L

DIMENIONS (LxWxH): 4500 x 1500 x 2810 mm

SYSTEM WATER VOL (L): 5,068

DRY WEIGHT (KG): 743

WET / RUNNING WEIGHT (KG): 5,811

POWER SUPPLY: 380V / 50Hz (110V available)

MAX POWER CONSUMPTION (kW): 3.88

RETURN PUMP: Badu Prime 40-AK

CIRCULATION PUMP: DC controllable, 220 W, 30,000 l/hr

SUMP: White PP, 3800L vol.

PROTEIN SKIMMER: Acrylic Body, Controllable Needle Wheel DC pump 30,000 l/hr

BIOLOGICAL FILTRATION: MBBR Chamber, K3 Media

PARTICULATE FILTER: High Pressure Sand filter, Fibreglass body, viewing window, 1150kg silica sand, 1200mm dia.

DEGAS / TRICKLE CHAMBER: Bio-balls degas media

UV STERILISER: High Output, PVC body, 3 x 120w bulb

PREFILTERS: 10 x 100 micron, 430 x 170 mm dia.

OCEANYX systems offer a wide range of upgrades and customizable options depending on the application and end user preference. Options include:

• Automated operating system

• Digital water parameter monitoring (Lab grade probes): Temperature / Salinity / KH / PH / ORP

• Water level monitoring / Automatic Top-up

• Water mixing / Top-up reservoir

• Automatic dosing system

• Ozone injection / Degassing system

• Water Chiller / Heat exchanger

• Remote monitoring and alarm from mobile Device
